· Netzwerk & Performance
· 8× 10/100/1000 Mbps RJ45 (PoE+)
· PoE-Standards: IEEE 802.3af/at, bis 30 W/Port, 80 W gesamt
· Non-blocking Gigabit-Switching, Store-and-Forward
· Auto-MDI/MDI-X
· Management (L2+)
· VLAN (Port-basiert / 802.1Q)
· QoS, IGMP Snooping, Broadcast- & Storm-Control
· Link Aggregation (LACP)
· Port Mirroring, Traffic Rate-Limiting
· Port Security & Access Control
· Web-GUI, SNMP (v1/v2c, modellabh. v3), CLI/Telnet/SSH
· Firmware- & Konfigurationsbackup
· Design & Montage
· Komplett lüfterlos
· Metallgehäuse
· 10-Zoll-Rackmontage
· Maße: ca. 250 × 150 × 42 mm, Gewicht: ca. 2 kg
· Elektrik & Umgebung
· Internes Netzteil, 100240 V AC
· Max. Leistungsaufnahme: ca. 96 W (lastabhängig)
· Betriebstemperatur: 040 °C, Lagerung: 1070 °C
· Luftfeuchtigkeit: 2085 %, nicht kondensierend
· 8× 10/100/1000 Mbps RJ45 (PoE+)
· PoE-Standards: IEEE 802.3af/at, bis 30 W/Port, 80 W gesamt
· Non-blocking Gigabit-Switching, Store-and-Forward
· Auto-MDI/MDI-X
· Management (L2+)
· VLAN (Port-basiert / 802.1Q)
· QoS, IGMP Snooping, Broadcast- & Storm-Control
· Link Aggregation (LACP)
· Port Mirroring, Traffic Rate-Limiting
· Port Security & Access Control
· Web-GUI, SNMP (v1/v2c, modellabh. v3), CLI/Telnet/SSH
· Firmware- & Konfigurationsbackup
· Design & Montage
· Komplett lüfterlos
· Metallgehäuse
· 10-Zoll-Rackmontage
· Maße: ca. 250 × 150 × 42 mm, Gewicht: ca. 2 kg
· Elektrik & Umgebung
· Internes Netzteil, 100240 V AC
· Max. Leistungsaufnahme: ca. 96 W (lastabhängig)
· Betriebstemperatur: 040 °C, Lagerung: 1070 °C
· Luftfeuchtigkeit: 2085 %, nicht kondensierend
| Allgemein | |
| Produktbeschreibung | DIGITUS DN-95331 - Switch - 8 Anschlüsse - managed - an Rack montierbar |
| Gerätetyp | Switch - 8 Anschlüsse - L2+ - managed |
| Gehäusetyp | An Rack montierbar 1U |
| Untertyp | Gigabit Ethernet |
| Ports | 8 x 10/100/1000 (PoE+) |
| Power Over Ethernet (PoE) | PoE+ |
| PoE-Budget | 80 W |
| Leistung | Bandbreite: 16 Gbit/s |
| Kapazität | Link-Aggregationsgruppen: 8 |
| Größe der MAC-Adresstabelle | 8000 Einträge |
| Jumbo-Rahmenunterstützung | 16KB |
| Routing Protocol | Statisches IP Routing |
| Remoteverwaltungsprotokoll | SNMP, RMON, Telnet, HTTP, SSH, CLI |
| Leistungsmerkmale | Flusskontrolle, ARP-Unterstützung, IGMP Snooping, Port-Spiegelung, IPv6-Unterstützung, Halbduplex-Modus, Vollduplex-Modus, WFQ, STP Support, RSTP-Unterstützung, MSTP Support, ACL Support, QoS, MLD-Snooping, Anschlussisolierung, SP, gekennzeichnetes VLAN, Metallgehäuse, 4,1-MB-Paketpuffer, ICMP, Link Aggregation, AAA, WRR, Loopback-Erkennung, Anschluss-basiertes VLAN, Multicast-Modus, DSCP based QoS |
| Produktzertifizierungen | IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at |
| Stromversorgung | Wechselstrom 120/230 V (50/60 Hz) |
| Abmessungen (Breite x Tiefe x Höhe) | 25 cm x 15 cm x 4.4 cm |
| Gewicht | 1.14 kg |
